SC 140 is usable for small amount of products packaging. With very compact dimensions, it is very useful in limited areas.
SC 140 can be used to pack wide range of products
Food – packing of meat, fish, salads, cheese, vegetables and other products
Medicine – packing of medical products
Pharmacy – packing of pharmaceutical products, tools and goods
Packing of industrial and consumer goods
Machine of this series is the best solution for the growing small manufacturers with limited production area. By using tested technologies and electronical and pneumatic spare parts of European well known manufacturers, packaging machines provide safe, precise and stable work during many years of operation.
Parameters
SC 140 main parameters
- Solid stainless steel frame, for safe transportation and for strengthening of systems and mechanisms.
- Durable gripper chain guides casing.
- All machines are equipped with servo drive system for gripper chain.
- Most of the spare parts are freely available on the market.
Type of packaging
- Only sealing of the package
- Vacuum and sealing
- Vacuum, gas and sealing
Longitudinal cutting
- Rotary knife assembly
Types of cutting
- Longitudinal and cross-cutting
Cross cutting
- Cross cutting unit for flexible film – straight cut
- Cross cutting unit for rigid film with round cornern
Types of forming
- Only with compressed air
Cut-off length
- 150, 200, 240, 270, (300) mm
Details of packages
- Max. forming depth (mm): Flexible film up to 80 m, Rigid film up to 40 mm
- Hanging hole – oval or round
- Hanging hole – “eiroslot”
Control system
- Colourful LCD touch screen
- Control elements from SMC Pneumatics, Schneider Electric, Allen Bradley, Busch and others
Specification of films
- Film width: from 320 and 420 mm
- Flexible film
- Thickness up to 100 microns
- Lower film: rigid film, flexible film
- Thickness: for rigid film up to 300 microns; for flexible film up to 400 microns
Potential options for our machines
- Labeller
- Data printer
- Dosing system
- Pad placer
Potential Options
Potential options for our machines
- Closed cooling system
- Supply system for protective gas
- Stainless steel gripper chain
- Automatic chain lubrication
